Single Core Tinned Copper Braided high temperature Insulation Shielded Wire
Applications
it is used for household appliances,Precision equipment,PTC thermistors,Temperature sensor,automotive internal connection, electronic and electrical appliances under high temperature
Features
1 .it's can be rated up to 250°C, thus making it an excellent choice for high temperature applications. Along with excellent temperature ratings, PFA has outstanding resistance to chemicals.
2. it has superior mechanical strength at high temperatures as compared to FEP insulation wire,and also remains flexible at low temperatures
3. Small diameter, wear resistant, scratch resistant, easy to peel, high and low temperature resistant, corrosion resistant, anti-interference etc.
Properties:
1. Rated voltage : 110V, 250V and 600V
2. Max. working temperature of the wire core: 200℃ and 250℃;
3. In the ambient temperature not less than -65℃ conditions still maintain the winding
4. Wire relative humidity: 95%±3.
5. Test voltage (AC 50Hz) 2000V/5min
6. Insulation resistance is greater than 1×103MΩ
Cross section area
mm2 | Conductormm | Conductor. Dia
mm | Insulation thickness
mm | Wire Diameter
mm | AC resistance at 20℃
Ω/km |
| AFkP type |
| 110V | 250V | 600V | 110V | 250V | 600V |
| 0.01 | 7×0.05 | 0.15 | 0.1 | 0.15 | 0.25 | 0.8 | 1 | 1.2 | 1345 |
| 0.04 | 7×0.08 | 0.24 | 0.1 | 0.15 | 0.25 | 0.9 | 1.1 | 1.3 | 550 |
| 0.06 | 7×0.10 | 0.3 | 0.1 | 0.15 | 0.25 | 0.95 | 1.15 | 1.35 | 340 |
| 0.08 | 7×0.12 | 0.36 | 0.1 | 0.15 | 0.25 | 1 | 1.2 | 1.4 | 230 |
| 0.12 | 7×0.16 | 0.48 | 0.1 | 0.15 | 0.25 | 1.15 | 1.35 | 1.6 | 145 |
| 0.2 | 7×0.20 | 0.6 | / | 0.15 | 0.25 | / | 1.55 | 1.8 | 82 |
| 19×0.12 | 0.6 | / | 0.15 | 0.25 | / | 1.55 | 1.8 | 85 |
| 0.3 | 19×0.16 | 0.8 | / | 0.15 | 0.25 | / | 1.7 | 2 | 54 |
| 0.5 | 19×0.18 | 0.9 | / | 0.15 | 0.25 | / | 1.85 | 2.1 | 38 |
| 0.75 | 19×0.23 | 1.15 | / | / | 0.25 | / | / | 2.4 | 23 |
| 1 | 19×0.26 | 1.3 | / | / | 0.3 | / | / | 2.7 | 18 |
| 1.5 | 19×0.32 | 1.6 | / | / | 0.3 | / | / | 3 | 13 |
| 49×0.18 | 1.62 | / | / | 0.3 | / | / | 3 | 15 |
| 49×0.20 | 1.8 | / | / | 0.3 | / | / | 3.2 | 12 |
| 2.5 | 49×0.26 | 2.34 | / | / | 0.4 | / | / | 4 | 7 |
| 3 | 49×0.28 | 2.52 | / | / | 0.4 | / | / | 4.2 | 6 |
| 4 | 49×0.32 | 2.88 | / | / | 0.4 | / | / | 4.6 | 5 |
| 6 | 49×0.39 | 3.51 | / | / | 0.4 | / | / | 5.2 | 3 |
